Recessed Linear Light

Availability: In Stock

Product Overview

The Recessed Linear Light delivers seamless architectural integration for clean, modern lighting effects. Designed to sit flush within walls, ceilings, or floors, it creates continuous lines of illumination that enhance both form and function. With multiple wattage options and a choice of white or dynamic RGBW colors, it’s ideal for highlighting contours, guiding pathways, or adding sophisticated accent lighting to façades and interiors.



Technical Specifications:

Wattage Options – 18W / 24W / 36W / 48W

Light Colours – White (WH), Warm White (WW), Neutral White (NWH), RGBW

Materials – Extruded aluminum profile with anti-corrosion treatment; tempered glass or polycarbonate diffuser

IP Rating – IP65 (outdoor weatherproof)

Lifespan – 50,000+ hours

Input Voltage – AC 100–277V, surge-protected

Beam Angle – 15°–120° (varies by diffuser type)

Mounting – Recessed housing for wall, ceiling, or floor integration

Applications:

Accent lighting for building outlines and architectural elements

Wall or ceiling embedded decorative illumination

Pathway and corridor guidance lighting

Retail and hospitality design accents

Guarantee Safe & Secure Checkout

Description

Installation Process:

Prepare the recessed channel in the wall, ceiling, or floor.

Fix the housing securely using mounting clips or screws.

Pass wiring through waterproof connectors to the terminal block.

Install the light module into the housing.

Connect to power, test, and adjust light direction if applicable.

Variants:

Wattages: 18W, 24W, 36W, 48W

Light Colors: WH, WW, NWH, RGBW

Control Options: Static, DMX for RGBW

Certificates and Reports:

BIS Certification

CE Compliance

RoHS Compliance

LM-79 Photometric Report

LM-80 LED Life Test Report

IP65 Ingress Protection Report
