Description
Installation Process:
Switch off the main power supply before installation.
Ensure the ceiling cutout matches the spotlight dimensions.
Connect live (L) and neutral (N) wires to the LED driver input terminals.
Attach the driver output connector to the spotlight ensuring correct polarity.
Insert the fixture into the ceiling using spring clips for a secure fit.
Restore power and verify illumination, focus, and beam angle alignment.
Check for stable, flicker-free operation and consistent light distribution.
Required Certificates and Reports:
BIS Certificate (ISI Mark) – Compliance with IS 10322 standards.
CE Certificate – Conformance to European safety and EMC standards.
RoHS Certificate – Restriction of hazardous substances in materials.
ISO 9001:2015 – Quality management certification for manufacturer.
LM-80 / TM-21 – LED chip lifetime and lumen maintenance validation.
IP Rating Certificate – Verified as per IEC 60529 (IP20 / IP44).
BEE / Energy Efficiency Certificate – Where applicable for regional compliance.
LM-79 Photometric Test Report – Light output, efficacy, CRI, and beam spread.
Electrical Safety Test Report – Insulation and dielectric performance verification.
Thermal Test Report – Confirms proper heat dissipation under rated wattage.
Surge Protection Test Report – As per IEC 61000-4-5 standards.
EMI/EMC Test Report – Ensures electromagnetic compatibility.
IP Rating Test Report – Confirms ingress protection as per specification.
