Description
Installation Process:
Cut an appropriate ceiling hole as per product cut-out size (varies by wattage).
Connect the LED driver to the main power supply (AC 85–265V).
Insert the COB spotlight housing into the ceiling cut-out using spring clips.
Ensure proper fitting and alignment for uniform beam direction.
Switch on the power supply to test illumination.
Variants:
Wattage : 3W / 7W / 12W
Color Temperature : WH / WW / NWH
Housing Finish : White / Black / Custom (on order)
Beam Angle : 24° / 36°
Dimmable / Non-Dimmable options
Certificates and Reports:
BIS (Bureau of Indian Standards) Certification
CE Certification
RoHS Compliance
ISO 9001:2015 (Quality Management)
ISO 14001:2015 (Environmental Management)
Required Test Reports :
LM-79 (Electrical & Photometric performance test)
LM-80 (LED chip life test report)
IP20 ingress protection test report
Safety and reliability testing (surge, thermal, dielectric strength)
Photobiological safety test (EN62471 compliance)
